JDT Over 5 ha Tractor mounted seeder for field crops (cotton, corn...)

The JDT is a large grain seeder designed by hands on specialised field engineers for from two to eight rows per bed. Created for market gardeners with 5 ha and more of beans, peas or sweet corn to sow in a day.

JDT
JDT seeding unit
799,00 € (without disks)
Add to cart
Choose at least 1 disk below
A-1
  • Number of holes : 8
  • Diameter ∅ : 9 mm
  • Hole Depth ↓ : 5 mm
  • Usable with the double row shoe :
45,00 €
A-2
  • Number of holes : 8
  • Diameter ∅ : 10 mm
  • Hole Depth ↓ : 6 mm
  • Usable with the double row shoe :
45,00 €

Options & Parts

The seeding units are independant and mounted on a bar for easy row spacing settings.

Precise and completely adjustable

Our tractor mounted seeder is easy to use, set up (some settings only require a 12 mm spanner) and very precise - the disk system allows one or two seeds to be extracted from the hopper at a time. A selection of drive chain sprockets are provided as standard equipment in order to set the spacing in the ridge. Planting depth is easily set by loosening a bolt on the plough assembly and tightening when the required depth is reached. The quantity of soil covering the seeds is equally easy to set by modifying the angle of the soil cover plates.

The JDT range is great value for money, and offers these unique features:

  • light weight and yet robust;
  • the seeds are protected by the use of soft, flexible fiber for the brush used to dose the seeds taken up by the seeding disk;
  • the unique transparent hopper is easier to clean and rust proof;
  • the hopper permits the user to see the quantity of seed it contains at all times - no running out of seed in the middle of a row;
  • it snaps on and off easily meaning there is no waste of left over seed - take it off and pour surplus seed back into the bag;
  • the distance betweens seeds has 11 different values possible thanks to the 6 sprockets provided as standard equipment;
  • depth set by a simple bolt on the plow assembly;
  • add the fertilizer distribution hopper for an all in one planting solution.

Theoritical spacing of spot seeding in mm

T series

Number of teeth per sprocket

Front

14

14

13

13

11

11

10

11

10

10

9

Rear

9

10

10

11

10

11

11

13

13

14

14

Number of teeth per sprocket

2

470

550

550

550

630

710

790

870

950

950

1110

6

150

170

180

190

210

240

260

280

310

310

360

8

110

130

140

140

160

180

200

210

230

230

270

16

60

70

70

70

80

90

100

110

120

120

140
